Parameter Estimation

This brief tutorial explains how to performance Bayesian parameter estimation of the quantum context effect model (QCEM) using Pigeons.jl. One complication in estimating the parameters of the QCEM is that the posterior distributions may have multiple modes, which leads to convergence problems with most MCMC algorithms. Pigeons.jl uses a special type of parallel tempering to overcome this challenge. An additional advantage of using Pigeons.jl is the ability to compute Bayes factors from the log marginal likelihood using the function stepping_stone.

Show Code

using QuantumContextEffectModels
using Plots
parms = (
    Ψ = sqrt.([.3,.1,.2,.4]),
    θil = .3,
    θpb = .3,
)
θils = range(-1, 1, length=1001)
preds = map(
        θil -> predict(
            QuantumModel(; parms..., θil);
            joint_func = get_joint_probs,
            n_way = 2
        ), θils)

preds = map(p -> p[5], preds)

preds = stack(preds)'
p1 = plot(θils[1:500], preds[1:500,:], leg=false, title="first half [-1,0)")
p2 = plot(θils[1:500], preds[501:end-1,:], leg=false, title="second half [0,1)")
plot(p1, p2, layout=(2,1))

Load Packages

First, we will load the required packages below.

using Pigeons
using QuantumContextEffectModels
using Random
using StatsPlots
using Turing

Generate Simulated Data

The next step is to generate some simulated data from which the parameters can be estimated. In the code block below, the utility parameter $\mu_d$ is set to one and the entanglement parameter is set to $\gamma = 2$. A total of 50 trials is generated for each of the three conditions. The resulting values represent the number of defections per condition out of 50.

Random.seed!(84)
n_trials = 25
n_way = 2
parms = (
    Ψ = sqrt.([.7,.1,.1,.1]),
    θil = .6,
    θpb = .3,
)
model = QuantumModel(; parms...)
data = rand(model, n_trials; n_way)

Define Turing Model

The next step is to define a Turing model with the @model macro. We will estimate the entanglement parameters using the prior $\gamma_j \sim \mathrm{normal}(0,3)$. The other parameters will be fixed to the data generating values defined in the code block above.

@model function turing_model(data, parms, n_trials; n_way)
    θil ~ Uniform(0, 1)
    θpb ~ Uniform(0, 1)
    model = QuantumModel(; parms..., θil, θpb)
    Turing.@addlogprob! logpdf(model, data, n_trials; n_way)
end

sampler = turing_model(data, parms, n_trials; n_way)

Estimate Parameters

To estimate the parameters, we need to pass the Turing model to pigeons. The second command converts the output to an MCMCChain object, which can be used for plotting

pt = pigeons(
    target=TuringLogPotential(sampler),
    record=[traces],
    multithreaded=true)
samples = Chains(sample_array(pt), ["θil", "θbp", "LL"])
plot(samples)

chain = sample(sampler, NUTS(1000, .85), MCMCThreads(), 1000, 4)
plot(chain)

The trace of the pigeon's sampler is given below:

────────────────────────────────────────────────────────────────────────────
  scans        Λ      log(Z₁/Z₀)   min(α)     mean(α)    min(αₑ)   mean(αₑ)
────────── ────────── ────────── ────────── ────────── ────────── ──────────
        2        4.9       -150          0      0.456      0.857      0.961
        4       2.47        402   1.61e-23      0.726      0.973      0.997
        8       5.03        444   0.000401      0.441          1          1
       16       5.27        459      0.136      0.415      0.993      0.999
       32       6.11        461     0.0646      0.321          1          1
       64       5.51        466      0.232      0.388          1          1
      128       5.13        470      0.257       0.43      0.997          1
      256       5.18        469      0.311      0.425      0.998          1
      512       5.14        469      0.347      0.429      0.999          1
 1.02e+03       5.14        469      0.398      0.429      0.998          1
────────────────────────────────────────────────────────────────────────────

Plot Posterior Distribution

Now we can plot the posterior distribution of $\gamma$ with plot. The posterior distribution of $\gamma$ has a primary mode around 1 and secondary modes around 2 and 3.5.

plot(samples)
